| CCT |
5600K±200K |
| CRI |
≥96 |
| TLCI |
≥96 |
| CQS |
≥94 |
| SSI (D55) |
≥72 |
| Beam Angle |
105° |
| Beam Angle (600 Series Hyper Reflector) |
55° |
| Power Consumption |
≤720W |
| Operating Current |
8A |
| Operating Voltage (Power Supply) |
100V~240V, 50Hz/60Hz |
| Operating Voltage (Battery) |
|
| Operating Voltage: V-Mount / Gold Mount (Two Batteries) Half Output |
12.5V-16.8V (14.4/15A) 22V-33.6V (26V/8.5A, 28.8V/7.5A) |
| Operating Voltage V-Mount / Gold Mount (Two Batteries) Full Output |
22V-33.6V (26V/18A, 28.8V/16A) |
| Operating Voltage (Battery) 3-Pin XLR (48V DC) |
48V/15A |
| Battery Charging (Voltage) |
16.8V/29.4V |
| Battery Charging (Amperage) |
3A |
| Operating Temperature |
-20°C~45°C |
| Control Methods |
On-board, 2.4GHz, Sidus Link (Sidus MeshTM), Art-net, LumenRadio |
| Wireless Operating Range (2.4GHz) |
≤100m |
| Wireless Operating Range (Bluetooth) |
≤80m |
| Wireless Operating Range (LumenRadio) |
≤100m |
| Screen Type |
Adaptive Brightness LCD |
| Firmware Upgradeable |
USB (FAT16/FAT32), Sidus Link OTA |
| Cooling Method |
Active Cooling |
| Weatherproofing |
Dust & Light Rain Resistant |
| Cable Type: Head Cable |
LS 600 Series 5-Pin Weatherproof Head Cable (3m) |
| Cable Type: Max Head Cable Length |
6m |
| Cable Type: Power Caple |
Neutrik® powerCON AC Power Cable (6m) |
| Accessory Mount |
Bowens Mount |
| Mounting |
16mm / 28mm | 5/8in (Baby Pin) / 1.125in (Junior Pin) |
| Carrying Case |
Telescoping Handle, Wheels |
| Weight: Lamp Head w/ Yoke |
4.64kg / 10.23lbs |
| Weight: Control Box (V-Mount) |
5.8kg / 12.79lbs |
| Weight: Control Box (Gold Mount) |
5.8kg / 12.79lbs |
| Weight: Lightening Clamp |
670g / 1.48lbs |
| Weight: Total w/ Case |
Total w/ Case |
| Dimensions: Lamp Head w/o Yoke |
30.8*15.61*15.01cm / 12.13*6.15*5.91in |
| Dimensions: Lamp Head w/ Yoke |
30.8*25.03*45.6cm / 12.13*9.85*17.95 in |
| Dimensions: Control Box (V-Mount) |
32.41*17.9*14.28cm / 12.76*7.05*5.62in |
| Dimensions: Control Box (Gold-Mount) |
32.41*17.9*13.27cm / 12.76*7.05*5.22in |
| Dimensions: Lightening Clamp |
10.35*8.74*12.5cm / 4.07*3.44*4.92in |
| Dimensions: Case |
62.5*43.5*39cm / 24.61*17.13*15.35in |
